6W/12W/16W/25W/30W/35W/55W/110W/165W UV Water Sterilizer

Description:

The sterilization efficiency is as high as 99.99%, widely used in medical, food processing and drinking water treatment fields
No secondary pollution, no by-products, UV technology avoids secondary pollution to water or the environment
Easy to install, modular design, no complicated construction required, just put the equipment into the water tank
Convenient maintenance, the maintenance cycle of ultraviolet disinfection equipment is long and the operation is simple
Maximum working water pressure: 8 bar(116psi), medium pressure UV sterilizer can still maintain stable performance in low temperature environment

+86-18915253915
+86-15861607966
+86-13357912665
+86-18861287595

sara@jsf-qx.com
cindy@jsf-qx.com
tina@jsf-qx.com

Get a quote
  • The lamp can be made in China

    Optimumambient temperature

    2-40C

    Shell material

     stainless steel 304,316(Optional)

    Ron

    <0.3ppm(0.3mgL)

    Hardness

    <7gpg(120mg/L)

    Turbidity

    <1NTU

    UVpenetration

    >75%

    Model Flow rate Reactor
    dimension
    (mm)
    lnlet/Outlet
    Port
    Package slze(cm) Lamp power UVLamp code Ballast code
    m²hr GPM
    RAB-004 0.07  0.3  200×50.8 1/4”Internal thread 56.5*36.5*51.5/30Set 4W T5-185 4W
    RAB-006 0.1  0.5  260×50.8 1/4"Internal thread 56.5*36.5*51.5/30Set 6W T5-245 6W
    RAB-012 0.2  315×50.8 1/4”Internal thread 56.5×41.5×51.5/30Set 12W T5-305 12W
    RAB-016 0.4  375×63.5 1/2External thread 46X38X63cm/20Set 16W T5-360 16W
    RAB-025 1.4  595×63.5 1/2External thread 68.5×38×47.5/15Set 25W T5-580 25W
    RAB-030 1.8  915×63.5 3/4”External thread 106.5×38×32.5/10Set 30W T5-900 30W
    RAB-035 2.0  955×63.5 3/4”External thread 106.5×38×32.5/10Set 35W T5-940 35W
    RAB-040 2.3  10  915×63.5 3/4”External thread 106.5×38×32.5/10Set 40W T5-900 40W
    RAB-055 2.7  12  955×63.5 3/4”External thread 106.5×38×32.5/10Set 55W T5-940 55W
